Question - You open a restaurant and hope to entice customers by hanging out a sign (Fig. 11.37). The uniform
horizontal beam supporting the sign is 1.50 m long, has a mass of 18.0 kg, and is hinged to the wall.
The sign itself is uniform with a mass of 28.0 kg and overall length of 1.20 m. The two wires
supporting the sign are each 32.0 cm long, are 90.0 cm apart, and are equally spaced from the middle
of the sign. The cable supporting the beam is 2.00 m long.
(a) What minimum tension must your cable be able to support without having your sign come crashing
(b) What minimum vertical force must the hinge be able to support without pulling out of the wall?

Solution Preview - No Solution Preview Available
